膜分離技術在沼氣提純中通過利用不同氣體在膜材料中的滲透速率差異實現分離，其優缺點與技術特性、應用場景密切相關，具體表現如下：

　　Membrane separation technology achieves separation in biogas purification by utilizing the differences in permeation rates of different gases in membrane materials. Its advantages and disadvantages are closely related to technical characteristics and application scenarios, as shown below:

　　膜分離沼氣提純的顯著優勢體現在效率與環保性上。該技術采用物理分離原理，無需添加化學試劑，整個過程無污染物產生，也不會改變沼氣的原有成分，能最大限度保留甲烷的純度。分離過程可在常溫下進行，無需高溫高壓條件，能耗相對較低，相比傳統的化學吸收法（如胺法），可節省 30% 以上的能源消耗，尤其適合中小型沼氣工程的長期運行。設備結構緊湊，由膜組件、壓縮機、真空泵等核心部件組成，占地面積小，安裝調試便捷，可快速投入使用，且易于實現自動化控制，通過傳感器監測膜兩側的壓力、流量等參數，自動調節運行狀態，減少人工干預，提升操作效率。此外，膜分離過程可連續進行，能適應沼氣產量的波動，在沼氣流量變化時仍保持穩定的提純效果，確保甲烷純度維持在 95% 以上（滿足天然氣入網標準）。

　　The significant advantages of membrane separation for biogas purification are reflected in efficiency and environmental friendliness. This technology adopts the principle of physical separation, without the need to add chemical reagents. The entire process produces no pollutants and does not change the original composition of biogas, which can maximize the retention of methane purity. The separation process can be carried out at room temperature without the need for high temperature and high pressure conditions, with relatively low energy consumption. Compared with traditional chemical absorption methods (such as amine method), it can save more than 30% of energy consumption, especially suitable for the long-term operation of small and medium-sized biogas projects. The equipment has a compact structure, consisting of core components such as membrane components, compressors, and vacuum pumps. It occupies a small area, is easy to install and debug, can be quickly put into use, and is easy to achieve automation control. By monitoring the pressure, flow rate, and other parameters on both sides of the membrane through sensors, the operating status is automatically adjusted, reducing manual intervention and improving operational efficiency. In addition, the membrane separation process can be carried out continuously, adapting to fluctuations in biogas production and maintaining stable purification efficiency even when biogas flow rate changes, ensuring that methane purity remains above 95% (meeting natural gas grid entry standards).

　　在適用場景與操作靈活性上，膜分離技術也有明顯優勢。對于沼氣中含有微量硫化氫、水汽等雜質的情況，可通過預處理（如脫硫、脫水）后直接進入膜分離系統，無需復雜的預處理工藝，適配性較強。膜組件可根據提純規模靈活組合，單組膜組件處理量不足時，可通過增加膜組件數量實現擴容，滿足不同產量沼氣的提純需求，尤其適合沼氣產量逐步增長的項目。運行過程中，設備維護簡單，主要對膜組件進行定期檢查和清潔，更換膜組件時無需停機，可在線完成，減少對生產連續性的影響，降低維護成本和時間成本。

　　Membrane separation technology also has significant advantages in terms of applicable scenarios and operational flexibility. For the presence of trace amounts of impurities such as hydrogen sulfide and water vapor in biogas, it can be directly introduced into the membrane separation system after pretreatment (such as desulfurization and dehydration), without the need for complex pretreatment processes, and has strong adaptability. Membrane modules can be flexibly combined according to the purification scale. When the processing capacity of a single group of membrane modules is insufficient, the expansion can be achieved by increasing the number of membrane modules to meet the purification needs of different yields of biogas, especially suitable for projects with gradually increasing biogas production. During operation, equipment maintenance is simple, with regular inspections and cleaning of membrane components. Replacement of membrane components does not require downtime and can be completed online, reducing the impact on production continuity and lowering maintenance and time costs.

　　然而，膜分離技術的局限性也較為突出，核心在于膜材料的性能制約。膜對氣體的選擇性和滲透性難以兼顧，高選擇性的膜往往滲透性較低，導致提純效率受限；而高滲透性的膜則選擇性不足，可能使甲烷隨其他氣體一同滲透，降低甲烷回收率（通?；厥章试?85%-92%）。膜材料易受沼氣中雜質影響，若預處理不徹底，硫化氫、水汽等會腐蝕膜表面或堵塞膜孔，導致膜性能下降、壽命縮短（一般膜的使用壽命為 3-5 年），增加更換成本。此外，膜的分離效果受溫度和壓力影響較大，低溫會降低氣體滲透速率，高溫則可能加速膜的老化，壓力波動會導致分離純度不穩定，因此需要穩定的運行環境，增加了系統控制的復雜度。

　　However, the limitations of membrane separation technology are also prominent, with the core being the performance constraints of membrane materials. The selectivity and permeability of membranes towards gases are difficult to balance, and highly selective membranes often have lower permeability, resulting in limited purification efficiency; However, highly permeable membranes have insufficient selectivity and may allow methane to permeate with other gases, reducing methane recovery rates (typically between 85% -92%). Membrane materials are easily affected by impurities in biogas. If pre-treatment is not thorough, hydrogen sulfide, water vapor, etc. can corrode the surface of the membrane or block the membrane pores, resulting in a decrease in membrane performance and a shortened lifespan (generally, the lifespan of the membrane is 3-5 years), increasing replacement costs. In addition, the separation efficiency of the membrane is greatly affected by temperature and pressure. Low temperatures can reduce the gas permeation rate, while high temperatures may accelerate membrane aging. Pressure fluctuations can lead to unstable separation purity, requiring a stable operating environment and increasing the complexity of system control.

　　在經濟性與適用范圍上，膜分離技術存在一定限制。初期設備投資較高，膜組件的制造工藝復雜，尤其是高性能復合膜的成本占設備總投資的 60% 以上，對資金有限的小型項目而言，初期投入壓力較大。雖然運行成本較低，但長期來看，膜組件的更換費用累計起來并不低，相比變壓吸附法，在 10 年以上的長期運行中總成本可能更高。對于沼氣中甲烷濃度較低（低于 50%）的情況，膜分離需要多次循環分離才能達到目標純度，會增加能耗和處理時間，效率優勢不明顯，更適合甲烷初始濃度在 60% 以上的沼氣提純。同時，膜分離產生的尾氣（主要含二氧化碳、氮氣）利用價值較低，通常直接排放，相比化學吸收法可回收二氧化碳的優勢，資源利用率稍顯不足。

　　There are certain limitations to membrane separation technology in terms of economy and applicability. The initial equipment investment is relatively high, and the manufacturing process of membrane components is complex. Especially, the cost of high-performance composite membranes accounts for more than 60% of the total equipment investment. For small-scale projects with limited funds, the initial investment pressure is relatively high. Although the operating cost is relatively low, in the long run, the cumulative cost of replacing membrane modules is not low. Compared to pressure swing adsorption, the total cost may be higher in long-term operation for more than 10 years. For situations where the methane concentration in biogas is low (below 50%), membrane separation requires multiple cycles of separation to achieve the target purity, which increases energy consumption and processing time. The efficiency advantage is not significant, and it is more suitable for purifying biogas with an initial methane concentration of over 60%. At the same time, the tail gas generated by membrane separation (mainly containing carbon dioxide and nitrogen) has low utilization value and is usually directly discharged. Compared with the advantage of chemical absorption method in recovering carbon dioxide, the resource utilization rate is slightly insufficient.
